Product Description

B2 Audio RAGE Series 6"" Dual 2"" Voice Coil 2-Ohm 350W RMS Subwoofer RAGE6-D2

This Listing Includes:

• (1) 6"" DVC 2-ohm RAGE Subwoofer

Experience powerful, precise bass with the B2 Audio RAGE6-D2 6"" Dual Voice Coil Subwoofer. With its robust construction and versatile impedance options, this subwoofer delivers deep, impactful bass across a wide frequency range. With a peak power handling of 700W and sensitivity of 86.2 dB, it ensures impressive performance in any audio setup.

Specifications:

• RMS Power Handling: 350W
• Max Power Handling: 700W
• Nominal Impedance: Dual 2 Ohm
• Voice Coil Diameter: 2""
• Frequency Response: 10 Hz ~ 500 Hz
• Sensitivity: 86.2 dB
• Magnet Weight: 140 oz
• Displacement Volume: 1.6 L / 0.056 cu.ft
• 12 AWG Wire Inputs For Push Terminals

Thiele & Small

• Free Air Resonance (Fs): 44.9 Hz
• Resistance (Re): 1.9 ohm
• Mechanical Factor (Qms): 6.17
• Electrical Factor (Qes): 0.53
• Total Factor (Qts): 0.49
• Mechanical Resistance (Rms): 2.77
• Equivalent Volume (Vas): 3.3 L
• Compliance (Cms): 130 um/N
• BL Factor (BL): 54.6 TM
• Moving Mass (Mms): 100 g
• Excursion Max (Xmax): 0.59"" / 15 mm

Measurements:

• Overall Diameter: 7.08"" / 180mm
• Mounting Diameter: 6.42 / 163mm
• Front Mount Baffle Cutout: 5.98"" / 152mm
• Overall Depth: 5.43"" / 138mm
• Mounting Depth: 4.60"" / 117mm

Enclosure Suggestions:

Sealed:

• 5 L / 0.178 cu.ft
• Qtc 0.405

Ported Compact:

• 12 L / 0.42 cu.ft
• Port: 2""
• Length : 9.43"" / 24cm
• FB: 42 Hz

Ported:

• 18 L / 0.636 cu.ft
• Port: 3""
• Length: 14.17"" / 36cm
• FB: 42hz

"
