Product Description
GP Elite Advanced Options
*Assembly Required*
NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.
____________________________
37hz
| Box External Dimensions Width x Height x Depth | 20.00" x 12.50" x 16.07" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.25 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 16.87 inch2 |
| Port Inlet Width x Height | 1.53" x 11.00" |
| Port Length | 21.54" |
____________________________
35hz
| Box External Dimensions Width x Height x Depth | 20.00" x 12.50" x 16.48" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.25 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 16.87 inch2 |
| Port Inlet Width x Height | 1.53" x 11.00" |
| Port Length | 24.66" |
____________________________
33hz
| Box External Dimensions Width x Height x Depth | 20.00" x 12.50" x 16.99" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.25 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 16.87 inch2 |
| Port Inlet Width x Height | 1.53" x 11.00" |
| Port Length | 28.36" |
____________________________
31hz
| Box External Dimensions Width x Height x Depth | 24.00" x 12.50" x 14.77" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.25 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 16.87 inch2 |
| Port Inlet Width x Height | 1.53" x 11.00" |
| Port Length | 32.81" |
____________________________
29hz
| Box External Dimensions Width x Height x Depth | 32.00" x 12.50" x 11.80" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.25 ft3 |
| Tuning Frequency | 29 Hz |
| Port Area | 16.87 inch2 |
| Port Inlet Width x Height | 1.53" x 11.00" |
| Port Length | 38.20" |
