BUILDING ON AN ICONIC SPEAKER
The Type-R speaker has been an iconic part of the car audio industry for many years but it was time for a modernization of the brand. Type-R speaker performance was certainly top notch but there is always room for improvement. Rather than redesigning the speakers from scratch, we kept the fundamental Type-R sound & style characteristics and updated them.
MORE REALISTIC HIGHS
The R-Series speakers use a new ring-type tweeter voice coil for increased efficiency and better tonal balance across the entire sound band, for improved overall sound quality.
A MORE BALANCED TRANSITION
As with many high-end speakers, the Type-R components incorporate Wave Guide technology in the form of a phase plug in the center of the woofer cone. The Wave Guide enhances in-car sound dispersion and helps eliminate phase distortion. Alpine’s unique Dynamic eXpander ring stiffens the cone around the Wave Guide, eliminating a big source of distortion in typical designs caused by cone flexing.
NEW STREAMLINED GRILL
The new metal mesh grille with the R-Series logo badge provides a classic, attractive look. The mesh design also provides added sturdiness to the grille’s edge, for better protection against intrusions on the side of the speaker.
Speaker Size | 6x8" |
Design | 2-Way |
Tweeter Design | 1" Dome |
Impedance (Ohms) | 4 |
Tweeter Composition | Silk |
| Woofer Composition | Multi-Layer Hybrid Fiber |
| Woofer Surround | Santoprene Rubber |
| Sensitivity (dB) | 89dB |
| Frequency Response (Hz) | 63 - 29k Hz |
| RMS Power Rating (Watts) | 100 |
| Peak Power Rating (Watts) | 300 |
| Top-mount Depth (Inches) | 2 9/16 |
| Bottom-mount Depth (inches) | |
| Cutout Diameter (inches) | |
| Grilles Included | No |
| Warranty | 1-Year |
